Vernier Control Cable with 10-32 Thread

Click for a larger picture of Vernier Control Cable with 10-32 Thread
View Catalog Page in PDF format

These heavy-duty cables are perfect for adjustable sway bars. The Vernier control knob eliminates the need for a separate detent mechanism for input control. It also allows for much finer adjustment than most detent handles can provide.

The Vernier control moves the cable 3/16 inch for each full turn of the 1.225" OD control knob. Depressing the button in the center of the knob allows rapid adjustment to either end of travel. From there, you can count the number of turns to reach your desired setting. The control is resistant to vibration and will generally remain at the set point, but a lock nut (provided) can be used to positively prevent changes to your setting.

The free end of the cable has 10-32 male threads to accept a variety of different fittings (sold separately). The free end of the housing is grooved for easy clip-in attachment. Use either our Bolt-Down Housing Clamp (Part No. 3464) or our Quick-Release Housing Clamp (Part No. 3465) for a compact and lightweight mount. Mounting clamps are sold separately. The Vernier end is designed to be mounted through a bracket or panel (such as the dash panel).

These cables have a working load rating of 60 pounds in compression and 120 pounds in tension. The length is measured from the tip of the threads of the free cable end to the mounting panel. All lengths have 3 inches of cable travel and a 3" minimum bend radius.

Standard Dimensions for Push-Pull Cables
Thread10-32 (SAE UNF), 7/8" long
Housing Groove
to Cable End (min)
5 1/4"
Housing Groove
to Cable End (max)
8 1/4"
Travel3"
All dimensions are +/- 1/4"


These cables are rated for operating temperatures up to 225° F (107° C). If your application will exceed this limit, you will need to insulate your cable with one of our insulation products such as Aeroquip Fire Sleeve (Part No. 3299-.44) or Thermo-Tec Thermo-Sleeve (Part No. 1835-125).

Enter desired order quantities below, then click the "Add selected quantities to cart" button.

Order Qty
Part No.
Desc.
Price
Stock Status

3462-20
Condition: New
SKU: 77074

20 inch Vernier Control Cable, 10-32 Thread

$108.99In Stock

3462-48
Condition: New
SKU: 29350

48 inch Vernier Control Cable, 10-32 Thread

$128.19In Stock

3462-60
Condition: New
SKU: 29351

60 inch Vernier Control Cable, 10-32 Thread

$130.99In Stock

3462-72
Condition: New
SKU: 29352

72 inch Vernier Control Cable, 10-32 Thread

$137.59In Stock

3462-84
Condition: New
SKU: 29353

84 inch Vernier Control Cable, 10-32 Thread

$139.99In Stock

3462-91
Condition: New
SKU: 43744

91 inch Vernier Control Cable, 10-32 Thread

$138.99In Stock

3462-96
Condition: New
SKU: 29354

96 inch Vernier Control Cable, 10-32 Thread

$137.99In Stock

3462-108
Condition: New
SKU: 29348

108 inch Vernier Control Cable, 10-32 Thread

$145.99In Stock

3462-120
Condition: New
SKU: 84895

120 inch Vernier Control Cable, 10-32 Thread

$147.99In Stock

3462-144
Condition: New
SKU: 86992

144 inch Vernier Control Cable, 10-32 Thread

$149.99In Stock

3462-192
Condition: New
SKU: 75746

192 inch Vernier Control Cable, 10-32 Thread

$164.99In Stock

3462-240
Condition: New
SKU: 82591

240 inch Vernier Control Cable, 10-32 Thread

$169.99In Stock

3462-288
Condition: New
SKU: 82592

288 inch Vernier Control Cable, 10-32 Thread

$199.99In Stock
