Staubli SPH Panel Mount High-Pressure Female Coupling, EPDM

Click for a larger picture of Staubli SPH Panel Mount High-Pressure Female Coupling, EPDM

Brand: Staubli

This item qualifies for FREE Shipping in the continental United States!

Staubli have been leaders in quick-release couplings for over 40 years. The SPH series are designed specifically for motorsport brake and clutch hydraulics, with many great features.

  • Compact: 5/8" diameter, 2" long (excluding AN fittings) when connected
  • Lightweight: Approximately 1 ounce per set
  • EPDM seals are compatible with brake fluid
  • 2900 psi (200 bar) pressure rating suitable for racing brake systems
  • No spillage when disconnected (spare calipers can be kept filled and ready to install)
  • No air allowed in (no need to bleed the system after reconnecting)
  • Bayonet locking system takes just a push and a twist to connect or disconnect
  • Male 3AN bulkhead fitting



The male 3AN bulkhead fitting on this version allows easy installation in a panel or bracket. This allows super-quick, one-handed connection and disconnection. Requires a 3/8" diameter hole and accomodates panel thickness between 0.04" and 0.2".

Note: "Female" refers to the internal valve mechanism, not to the retention sleeve. The Female SPH coupling has the female valve and fits inside the retention sleeve on the male coupling.

Enter desired order quantities below, then click the "Add selected quantities to cart" button.

Order Qty
Part No.
Desc.
Price
Status

4700-025-03-Red
Condition: New
SKU: 57535

Staubli Female Panel Mount Coupler, Male 3AN Fitting, EPDM

1 to 3: $269.99

4 & up: $258.47

In Stock

4700-025-03-YEL
Condition: New
SKU: 76583

Staubli Female Panel Mount Coupler, Male 3AN, Yellow, EPDM

1 to 3: $269.99

4 & up: $258.47

In Stock
