Brand: AIM Sports
This rotary sensor measures up to approximately 25mm (1 inch) of linear travel. Also known as the "String Type" throttle position sensor because it connects to your throttle pedal or linkage with a string or thread. As you press the pedal, the string pulls on the rotary arm of the sensor.
This arrangement offers a safety advantage over linear (telescoping) sensors: If the sensor malfunctions and sticks, the string will collapse instead of holding the throttle open. It is also less prone to damage due to unexpected lateral motion. For use with all AiM MyChron3, MXL, MXL2/MXG/MXS, and EVO Series automotive dashes and data loggers.
This sensor has the 719 (four-pin plastic push-on type) connector. Use an AiM 719-719 Extension Cable (Part No. MC-211) to connect to the sensor harness on AiM MXL series dashes, the MyChron3 Gold Auto dash, the EVO3 data logger, or the EVO5 data logger. The MyChron3 XG-Log dash, EVO4 / EVO4S loggers, and the Channel Expansion Hub require the AiM 719-712 Adapter Cable (Part No. MC-210).
