Tilton 3-Pedal Assembly, 5.29 - 5.75 Ratio, Floor Mt, Alum

Click for a larger picture of Tilton 3-Pedal Assembly, 5.29 - 5.75 Ratio, Floor Mt, Alum
Click for a larger picture of Tilton 3-Pedal Assembly, 5.29 - 5.75 Ratio, Floor Mt, Alum
View Catalog Page in PDF format

Brand: Tilton Engineering

This item qualifies for FREE Shipping in the continental United States!

Tilton's 3-pedal floor-mount pedal assembly offers an all inclusive system that is simple to install and service, making it suitable for a wide range of applications. This lightweight yet strong aluminum assembly includes Brake, Clutch, and Throttle pedals all in one system.

All three pedal pads are independently adjustable for height and spacing between the pedal pads (3/4" height adjustment in 3/16" increments, 9/16" lateral in 3/16" increments).
The Clutch pedal is designed for hydraulic actuation and has a built-in adjustable pedal stop.
The Brake pedal is designed for dual master cylinders and includes a 7/16" brake balance bar built in.
The Throttle pedal is contoured to avoid interference with your brake bias adjuster cable (sold separately). A cut-to-length extension tube for rear-engine applications moves the throttle cable away from your foot.
Uses standard master cylinders (not included) with 2.25" mounting bolt spacing and 5/16-24 pushrods (such as Tilton 74, 75, or 76 series; vintage-type Girling or Lockheed; Wilwood GS-Series, Compact Remote Flange Mount, or Combination Remote type).

Note: Three master cylinders, 7/16-20 remote bias adjuster, and throttle linkage kit sold separately.

Qty
Part No.
Price
Stock Status
TE 72-603

Condition: New

$442.00
In Stock
