Facet Mounting Kit for Fuel Pumps

Click for a larger picture of Facet Mounting Kit for Fuel Pumps
View Catalog Page in PDF format

This Fuel Pump Mounting Kit includes two rubber shock mounts, four matching locknuts, and a ground strap. Provides quieter pump operation and allows Facet Cylindrical pumps to be used on positive-ground vehicles.

For positive-ground hookups:
1. Connect the power (negative) wire from the vehicle to the top post of one of the shock mounts so that it makes contact with the pump mounting flange.
2. Connect the power (positive) wire from the pump to the bottom of one of the shock mounts so that it makes contact with the chassis of the vehicle. The ground strap in this kit will not be used.
Follow this link for an illustration of How to Install a Negative-Ground Pump in a Positive-Ground Car.

Qty
Part No.
Price
Stock Status
1130

Condition: New

$11.99
In Stock


A little too soft

3

I bought these to insulate a fuel pump. They're too soft. With only two mounts and the pump mounted vertical, the pump was pulling hard on top one, I didn't want the rubber to separate. I mounting flat, they'd be OK. I did not use 'em.

Racergu99

Illinois

false

Perfect addition to a facet pump

5

This product worked perfectly. The facet taps like a woodpecker without isolating it from the frame. Follow the directions and mount the pump at a 45 degree angle, flow is down hill. Installed in the empty passenger side battery box on a 1967 MGB GT. Car was covered to negative ground, one 12v battery is in the driver side battery box. Works great.

David

Harpers Ferry, WV

true

Facet mounting kit

5

Isolates the fuel pump from the chassis.

Sh

Florida

true

Isolates pump to reduce noise and allows polarity change.

5

This kit is very useful for mounting the pump to reduce operating noise, give some flexibility with rigid tube systems and allow positive ground use with single wire pumps by electrical isolating the pump body from the vehicle. The rubber standoffs are very well bonded and I have never had one come apart. The attachment nuts have built-in lock washers. A great product and good value.

Peter D

Jonesborough TN

true

Excellent product.

5

I bought two Facet mounting kits, one for my '63 Triumph TR4 and one for my wife's '67 Sunbeam Alpine Series V. With planning the mounts fit very well, and I recommend them.

Fat_Dog_Garage

Richmond, VA

true

Useful fuel pump accessory

4

The mounting kit is useful where the negative ground lead is tied to the pump body and you want to make a positive ground installation. The rubber mounts isolate the pump body from the car chassis. They also reduce operating noise and strain on the fuel lines.

Peter D

Jonesborough TN

true

Facet Mounting Kit for Fuel Pumps
