Part No.: 3460-Size

Push-Pull Cable with Clip-in Ends

These heavy-duty cables are often used on adjustable sway bars, but they also work very well as shifter cables. Their operation is so smooth, some of our customers even use them as throttle cables. The 3" minimum bend radius lets them fit very tight installations. These cables have a working load rating of 60 pounds in compression and 120 pounds in tension. The stainless steel inner core makes them suitable for marine use.

Both ends of the housing are grooved (1/4" / 6mm OD) for easy clip-in attachment. This provides a compact and lightweight means of mounting with either our Bolt-Down Housing Clamp (Part No. 3464) or Quick-Release Housing Clamp (Part No. 3465). Length is measured from end-to-end of the inner cable including the threaded ends. Housing clamps sold separately.

Standard Dimensions for Push-Pull Cables
Thread10-32
Housing Groove
to Cable End (min)
5 1/4"
Housing Groove
to Cable End (max)
8 1/4"
Travel3"
Jacket Length
(Groove to Groove)
End-to-End Length
Minus 13 1/2"
All dimensions are +/- 1/4"


These cables are rated for operating temperatures up to 225° F (107° C). If your application will exceed this limit, you will need to insulate your cable with one of our insulation products such as Aeroquip Fire Sleeve (Part No. 3299-.44) or Thermo-Tec Thermo-Sleeve (Part No. 1835-125).

Click image for big picture

Click for a larger picture of Push-Pull Cable with Clip-in Ends


View Catalog Page in PDF format

Order Qty
Part Number
Description
Price
Status

3460-30

30 inch Push-Pull Cable with Clip-in Ends $49.99 Not In Stock
notify me when available

3460-32

32 inch Push-Pull Cable with Clip-in Ends $49.99 In Stock

3460-38

38 inch Push-Pull Cable with Clip-in Ends $53.99 Not In Stock
notify me when available

3460-44

44 inch Push-Pull Cable with Clip-in Ends $53.99 In Stock

3460-48

48 inch Push-Pull Cable with Clip-in Ends $53.99 In Stock

3460-51

51 inch Push-Pull Cable with Clip-in Ends $58.99 Not In Stock
notify me when available

3460-52

52 inch Push-Pull Cable with Clip-in Ends $58.99 Not In Stock
notify me when available

3460-54

54 inch Push-Pull Cable with Clip-in Ends $58.99 In Stock

3460-60

60 inch Push-Pull Cable with Clip-in Ends $58.99 In Stock

3460-72

72 inch Push-Pull Cable with Clip-in Ends $64.99 In Stock

3460-84

84 inch Push-Pull Cable with Clip-in Ends $69.99 In Stock

3460-90

90 inch Push-Pull Cable with Clip-in Ends $72.99 Not In Stock
notify me when available

3460-96

96 inch Push-Pull Cable with Clip-in Ends $72.99 In Stock

3460-100

100 inch Push-Pull Cable with Clip-in Ends $75.99 Not In Stock
notify me when available

3460-107

107 inch Push-Pull Cable with Clip-in Ends $75.99 In Stock

3460-108

108 inch Push-Pull Cable with Clip-in Ends $75.99 In Stock

3460-112

112 inch Push-Pull Cable with Clip-in Ends $78.99 Not In Stock
notify me when available

3460-120

120 inch Push-Pull Cable with Clip-in Ends $78.99 Not In Stock
notify me when available

3460-36

36 inch Push-Pull Cable with Clip-in Ends $49.99 Not In Stock
notify me when available

Call for Quote

3460-XXX

Push-Pull Cable with Clip-in Ends - specify length Call for Quote Special Order
