Non-AiM Single Rear Camera Patch Cable

Click for a larger picture of Non-AiM Single Rear Camera Patch Cable

Brand: AIM Sports

This special cable is intended specifically to connect a single analog camera (such as ASIN B01H1RFZYA, available from Amazon) to your AiM "1.2" version MX-Series dash (MXS 1.2, MXP, or MXG 1.2 including Strada versions). The extra-long 5 meter (16 foot 5 inch) cable is long enough for backup-camera mounting in many applications.

One RCA plug-in connector and one DC power plug at one end connect to the stock plugs on the camera, and a 5-pin male 712 screw-in Binder connector at the other end screws into the 5-pin port between the two large harness connectors on the back of the dash. Cables are sold individually.

Note 1: This adapter cable is specifically designed to work with a camera that has a single female DC plug and a single RCA female plug. It will not connect to the AiM version of the camera (with a 712 connector cable).
Note 2: Some cameras on the market have the correct connectors but run on 3.3V power. The AiM MX-Series 1.2 dashes provide a "battery voltage" (e.g., 12 volts in a 12V system) power supply. Be sure to check the specs on your camera before connecting it! You may need to rewire your camera to step down the voltage from the AiM dash.

Part No.
Stock Status

Condition: New

In Stock
